The Kahuna is one of our best-selling hardtails. People love its simplicity and practicality. We brought that ethos to the El Kahuna and built a bike that was multipurpose—capable of riding the local singletrack for hours on end, and still have enough battery to go get the groceries on the way home. Its Shimano pedal-assist motor is powered by a semi-integrated battery and its 100mm fork provides just the right amount of suspension to absorb smaller hits on the trail. 29” wheels with 2.25” tires make this bike comfortable across all kinds of terrain. The El Kahuna the perfect all-rounder.
| Frame Material | Kona 6061 Aluminum Butted |
| Sizes | S, M, L, XL |
| Fork | Suntour XCR34 Air 100mm Tapered 110 Spacing |
| Crankarms | FSA E-Bike |
| Chainrings | 36t |
| Pedals | N/a |
| Chain | Shimano HG54 |
| Cassette | Sunrace 11-46t 10spd |
| Chainguide | N/a |
| Rear Derailleur | Shimano Deore |
| Shifters | Shimano Deore |
| Brake Calipers | Shimano MT410 |
| Front Brake Rotor | Shimano RT10 180mm (centerlock) |
| Rear Brake Rotor | Shimano RT10 160mm (centerlock) |
| Brake Levers | Shimano MT401 |
| Headset | FSA No.57BP |
| Handlebar | Kona XC/BC Riser |
| Stem | Kona XC |
| Seatpost | Kona Thumb w/Offset 31.6mm |
| Seat Clamp | Kona QR |
| Grips | Kona Key Grip |
| Saddle | WTB Volt |
| Front Hub | Formula 110x15mm |
| Rear Hub | Shimano 135x10mm |
| Spokes | Stainless 14g |
| Rims | WTB ST i27 TCS 2.0 |
| Front Tyre | WTB Trail Boss 29×2.25″ |
| Rear Tyre | WTB Trail Boss 29×2.25″ |
| Batterylock | Abus |
| Paint Colour | Gloss Plum w/ Metallic Brass & Matte Ink Decals |
| Extras | N/a |
| Drive Unit | Shimano E6100 20MPH |
| Battery | Shimano 504Wh |
| Charger | Shimano STEPS 2A |
| Display | Shimano SC-E7000 Display |
| Max. Speed | Easily adjustable up to 32kmph |
| Range | Up to 100 kilometers with standard battery |
| Power modes | 3 levels of pedal assist mode |
